8. CONNECTORSDESCRIPTIONS FOR α series
97
Model Name [C] Cable Clamp
[B] Elbow Type Plug Connec-
tor
[A] Straight Type Plug Con-
nector
α12/2000, α12/3000
α22/1500, α22/2000
α30/1200
αC12/2000, αC22/1500
α12/3000HV
α22/3000HV
α30/3000HV
α40/2000HV
αM22/3000HV
αM30/3000HV
αM40/3000HV
MS3106B22–22S–(A72)
(Japan Aviation Electronics Indus-
try)
H/MSA3106A22–22S(10)
(Hirose Electric)
MS3106B22–22S–B
(DDK Ltd.)
MS3108B22–22S–(A72)
(Japan Aviation Electronics Indus-
try)
H/MSA3108B22–22S(10)
(Hirose Electric)
MS3108B22–22S–B
(DDK Ltd.)
MS3057–12A–(A72)
(Japan Aviation Electronics Indus-
try)
H/MSA3057–12A(10)
(Hirose Electric)
MS3057–12A(D265)
(DDK Ltd.)
α22/3000, α30/2000
α30/3000, α40/2000
α40/2000FAN (*1)
αM22/3000
αM30/3000
αM40/3000
αM40/3000FAN (*1)
αL25/3000
αL50/2000
MS3106B24–10S–(A72)
(Japan Aviation Electronics Indus-
try)
H/MSA3106A24–10S(10)
(Hirose Electric)
MS3106A24–10S–B
(DDK Ltd.)
MS3108B24–10S–(A72)
(Japan Aviation Electronics Indus-
try)
H/MSA3108B24–10S(10)
(Hirose Electric)
MS3108B24–10S–B
(DDK Ltd.)
MS3057–16A–(A72)
(Japan Aviation Electronics Indus-
try)
H/MSA3057–16A(10)
(Hirose Electric)
MS3057–16A(D265)
(DDK Ltd.)
For Signal
Common to all models
MS3106B20–29SW–(A72)
(Japan Aviation Electronics Indus-
try)
H/MSA3106A20–29SW(11)
(Hirose Electric)
MS3106A20–29SW–B
(DDK Ltd.)
MS3108B20–29SW–(A72)
(Japan Aviation Electronics Indus-
try)
H/MSA3108B20–29SW(11)
(Hirose Electric)
MS3108B20–29SW–B
(DDK Ltd.)
MS3057–12A–(A72)
(Japan Aviation Electronics Indus-
try)
H/MSA3057–12A(10)
(Hirose Electric)
MS3057–12A(D265)
(DDK Ltd.)
For Brake
Common to all models
(excluding αHV series)*1
MS3106B10SL–3S–(A72)
(Japan Aviation Electronics Indus-
try)
H/MSA3106A10SL–3S(10)
(Hirose Electric)
MS3106A10SL–3S–B
(DDK Ltd.)
MS3108B10SL–3S–(A72)
(Japan Aviation Electronics Indus-
try)
H/MSA3108B10SL–3S(10)
(Hirose Electric)
MS3108A10SL–3S–B
(DDK Ltd.)
MS3057–4A–(A72)
(Japan Aviation Electronics Indus-
try)
H/MSA3057–4A(10)
(Hirose Electric)
MS3057–4A(D265)
(DDK Ltd.)
αHV series
MS3106B10SL–4S–(A72)
(Japan Aviation Electronics Indus-
try)
H/MSA3106A10SL–4S(10)
(Hirose Electric)
MS3106A10SL–4S–B
(DDK Ltd.)
MS3108B10SL–4S–(A72)
(Japan Aviation Electronics Indus-
try)
H/MSA3108B10SL–4S(10)
(Hirose Electric)
MS3108A10SL–4S–B
(DDK Ltd.)
MS3057–4A–(A72)
(Japan Aviation Electronics Indus-
try)
H/MSA3057–4A(10)
(Hirose Electric)
MS3057–4A(D265)
(DDK Ltd.)
*1 The connector for the α40 fan or αM40 fan is the same connector used
on a standard brake.
The table only examples. Contact each manufacturer for details.
