1. GENERALFANUC AC SERVO MOTOR αC series
201
1
GENERAL
The FANUC AC servo motor αC series is suitable for application to the
feed axes of machine tools. These motors have the following features:
High cost–effectiveness has been achieved. Although a low–power
amplifier is used, high acceleration is offered.
The use of the latest ferrite magnet, combined with an optimized
mechanical design, reduces both the overall length and weight. The result
is compact, lightweight servo motors.
The use of waterproof connectors and FANUC’s unique stator seal
provide excellent waterproofing, ensuring that no liquid, such as coolant,
can enter the motor.
Further improvements have been made to the unique magnetic pole shape
to minimize torque ripple. The result is extremely smooth rotation.
The use of the latest servo software maintains controllability even when
a disturbance occurs.
High–resolution pulse coder αA1000, αA64, αI64 is used in the standard
configuration, enabling precise positioning.
A powerful brake with an increased holding torque is available as an
option. The brake uses an asbestos–free design.
The αC series includes models αC3 and αC6, both of which are
compatible with α series models α3 and α6 in their installation size, and
models αC12 and αC22, which are compatible with series models α12
and α22 in their installation size.
High cost–effectiveness
Compact
Excellent waterproofing
Smooth rotation
Controllability
High–performance
detector
Powerful brake
