AC SERVO MOTOR Alpha series Descriptions Page 134

Descriptions
3.SPECIFICATIONS AND
CHARACTERISTICS
B–65142E/04
FANUC AC SERVO MOTOR α series
118
Specification : A06B–0146–Bjjj
Specification : A06B–0147–Bjjj
Specification : A06B–0148–Bjjj
Speed – torque characteristics
Speed (min
–1
)
”ON” time (min.)
Over load duty
Torque
(Nm)
Duty
(time %)
Intermittent
operating
Continuous
operating
Data sheet
Parameter Symbol Value Unit
Rating rotation speed Nmax 1500 2000 3000 min
-1
Rated torque at stall (*) Ts
22
224
22
224
22
224
Nm
kgfcm
Rotor inertia Jm
0.012
0.12
0.012
0.12
0.012
0.12
kgm
2
kgfcms
2
Continuous RMS current at stall
(*)
Is 12.5 18.7 32.1 A (rms)
Torque constant (*) Kt
1.76
18.0
1.17
12.0
0.68
7.0
Nm/A (rms)
kgfcm/A (rms)
Back EMF constant (1–phase)
(*)
(*)
Ke
Kv
62
0.59
41
0.39
24
0.23
V (rms)/1000min
-1
V (rms)·sec/rad
Armature resistance (1–phase)
(*)
Ra 0.315 0.140 0.049 Ω
Mechanical time constant (*) tm 0.004 0.004 0.004 s
Thermal time constant tt 65 65 65 min
Static friction Tf
1.2
12
1.2
12
1.2
12
Nm
kgfcm
Mass 29 29 29 kg
(*)The values are the standard values at 20°C and the tolerance is "10%.
The speed–torque characteristics very depending on the type of software, parameter
setting, and input voltage of the digital servo motor. (The above figures show average
values.) These values may be changed without prior notice.
Model α22/1500
Model α22/2000
Model α22/3000
