AC SERVO MOTOR Alpha series Descriptions Page 78

Descriptions
5. CONDITIONS FOR APPROVAL
RELATED TO THE IEC34
STANDARD
B–65142E/04
DESCRIPTIONS FOR THE α series
62
D Also see Section 8.
D The power cable for the α22/3000, α30/2000, α30/3000, α40/2000,
α40/2000FAN, αM22/3000, αM30/3000, αL25/3000, and
αL50/2000 has 7 conductors. Its grounding wire (one conductor)
must have a cross section not less than that for the U, V, or W line (two
conductors). For the grounding wire for the other connectors, its cross
section must not be less than that for the U, V, or W line.
D TUV have certified that the plug connector and cable clamp mentioned
above, when combined with the FANUC α series servo motors, satisfy
the VDE0627 safety standard. As indicated in the table below, several
manufacturers offer other plug connectors. For information about
whether the plug connectors satisfy the safety standard when
combined with the FANUC α series servo motors, contact the
corresponding manufacturer. Contact the manufacturers if you require
details of their products.
Manufacturer Product series name
Hirose Electric (HRS) H/MS310 TUV–conforming series
Japan Aviation Electronics Industry
(JAE)
JL04V series
DDK Ltd. (DDK) CE05 series
D If a cable or conduit hose seal adapter is used, consult an appropriate
connector maker.
