AC SERVO MOTOR Alpha series Descriptions Page 27

Descriptions
B–65142E/04
2. PRECAUTIONS ON USEDESCRIPTIONS FOR THE α series
11
Servo motor
Servo amplifier module (SVM)/
Servo amplifier unit (SVU)
Model name Connection axisSpecificationModel nameSpecification
a3/3000HV
a6/3000HV
A06B–0171–B***
A06B–0172–B***
SVM1–20HV A06B–6085–H102
A06B–6097–H102
SVM2–20/20HV A06B–6085–H201
A06B–6097–H201
L and M axes
SVM2–20/40HV A06B–6085–H202
A06B–6097–H202
L axis
SVM2–20/60HV A06B–6085–H203
A06B–6097–H203
L axis
a12/3000HV
aM6/3000HV
a
A06B–0176–B***
A06B–0182–B***
SVM1–40HV A06B–6085–H103
A06B–6097–H103
aM9/3000HV A06B–0183–B***
SVM2–20/40HV A06B–6085–H202
A06B–6097–H202
M axis
SVM2–40/40HV A06B–6085–H204
A06B–6097–H204
L and M axes
SVM2–40/60HV A06B–6085–H205
A06B–6097–H205
L axis
a22/3000HV
a30/3000HV
a
A06B–0177–B***
A06B–0178–B***
SVM1–60HV A06B–6085–H104
A06B–6097–H104
aM22/3000HV
aM30/3000HV
A06B–0185–B***
A06B–0186–B***
SVM2–20/60HV A06B–6085–H203
A06B–6097–H203
M axis
SVM2–40/60HV A06B–6085–H205
A06B–6097–H205
M axis
SVM2–60/60HV A06B–6085–H207
A06B–6097–H207
L and M axes
α40/2000HV A06B–0179–B*** SVM1–80HV A06B–6097–H105 (Note 9)
αM40/3000HV A06B–0189–B*** SVM1–80HV A06B–6097–H105 (Note 9)
α1000/2000HV A06B–0131–B*** SVM1–320HV
2 modules /1motor
A06B–6097–H107
(FSSB interface)
Servo motor Dynamic Brake modules(DBM)
Model name Specification Model name Specification
a300/2000
a400/2000
A06B–0137–B***
A06B–0138–B***
DBM
2 modules /1motor
A06B–6079–H401
a1000/2000HV A06B–0131–B*** DBM
2 modules /1motor
A06B–6079–H401
Previous page
Next page
