2.TYPES OF MOTORS
AND DESIGNATION
B–65142E/04
FANUC AC SERVO MOTOR α (HV) series
222
2
TYPES OF MOTORS AND DESIGNATION
The types and specifications of α(HV) series servo motors are described
as follows.
A06B–01jj–Bl ff
jj
71 : Model α3/3000HV
72 : Model α6/3000HV
l
0 : Taper shaft (standard)
2 : Taper shaft with the brake (8Nm/24VDC)
5 : Straight shaft
7 : Straight shaft with the brake (8Nm/24VDC)
ff
75 : Pulse coder αA64
77 : Pulse coder αI64
88 : Pulse coder αA1000
The standard shafts used for models α3/3000HV and α6/3000HV are
taper shafts. Use a taper shaft as far as circumstances, such as the delivery
time and maintenance, permit.
A06B–01jj–Bl ff
jj
76 : Model α12/3000HV
77 : Model α22/3000HV
78 : Model α30/3000HV
l
0 : Straight shaft (standard)
2 : Straight shaft with the brake (35Nm/24VDC)
5 : Taper shaft
7 : Taper shaft with the brake (35Nm/24VDC)
ff
75 : Pulse coder αA64
77 : Pulse coder αI64
88 : Pulse coder αA1000
A straight shaft is fitted as the standard shaft for models α12/3000HV,
α22/3000HV and α30/3000HV. When early delivery and case–of–
maintenance are important, a straight shaft should be used.
Models
α3/3000HV and
α6/3000HV
Models
α12/3000HV, α22/3000HV
and α30/3000HV
