AC SERVO MOTOR Alpha series Descriptions Page 3

Descriptions
s–1
SAFETY PRECAUTIONS
FANUC SERVO MOTOR series
This ”Safety Precautions” section describes the precautions which must be observed to ensure safety when using
FANUC servo motors (including spindle motors). Users of any servo motor model are requested to read this
manual carefully before using the servo motor.
The users are also requested to read this manual carefully and understand each function of the motor for correct
use.
The users are basically forbidden to do any behavior or action not mentioned in the ”Safety Precautions.” They
are invited to ask FANUC previously about what behavior or action is prohibited.
Contents
1. DEFINITION OF WARNING, CAUTION, AND NOTE s–2. . . . . . . . . . . . . . . . . . . . . . .
2. WARNING s–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3. CAUTION s–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4. NOTE s–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
