PROGRAMMING 18. SPECIFYING THE LASER FUNCTION

B–63194EN/02

347

15007

#6 #5 #4

XSC

ECK

ESE

#1 #0

[Data type] Bit

ESE If piercing is to be executed in edge machining, it is:

0 : Executed upon the completion of distribution.

1 : Executed after a smoothing error check is performed upon the

completion of distribution.

ECK In edge machining, the angle is judged with:

0 : The actual machining path.

1 : The path in the machining program.

XSC In exact stop mode, the edge machining function is:

0 : Not executed.

1 : Executed.

OVE15010

#6 #5 #4 #3 #2 #1 #0

[Data type] Bit

OVE Edge machining and feedrate clamp by arc radius:

0 : Cannot be used at the same time.

1 : Can be used at the same time.

S To use this function, the optional machining condition setting function

is required.

S When this function is used, the automatic corner override function and

feedrate clamp function based on an arc radius cannot be used.

S This function cannot be used together with automatic corner

deceleration.

S Edge machining cannot be performed with the single block function

or dry run function.

S This function can be used together only with X–Y plane facing.

It cannot be used together with any other function (such as cylindrical

interpolation, normal–direction control, or three–dimensional

cutting).

The edge machining function determines the angle between two cutting

blocks to perform machining at the start of the latter block according to

the set machining conditions. On the other hand, when movement is made

from G24 (piercing) to a cutting block, the startup machining function

machines the set return distance according to the set machining

conditions.

When selecting startup machining mode, set a desired number from 201

to 205 in the startup selection item on the machining data group screen

of the machining condition setting screen in the same way as in edge

machining mode selection. At this time, the same number can be set for

both edge machining and startup machining. Moreover, only startup

machining mode can be selected without selecting edge machining mode.

When startup machining mode need not be selected, set 0.

Limitations

18.7.4

Startup Machining

Function

Startup machining mode

selection
