APPENDIX

B–63194EN/02

G. ALARM LIST

763

Number ContentsMessage

5060 ILLEGAL PARAMETER IN

G02.3/G03.3

Parameter setting is illegal.

No. 5641 (setting of the linear axis) is not specified.

No. 5641 specifies an axis other than a linear axis.

No. 5642 (setting of the rotation axis) is not specified.

No. 5642 specifies an axis other than a rotation axis.

The CNC cannot control the linear or rotation axis (the value of No.

1010 is exceeded).

5061 ILLEGAL FORMAT IN G02.3/G03.3 The command for exponential interpolation (G02.3/G03.3) contains a

format error.

Address I, J, or K is not specified.

Addresses I, J, and K are 0.

5062 ILLEGAL COMMAND IN

G02.3/G03.3

The command for exponential interpolation (G02.3/G03.3) contains

an illegal value.

The specified value is not suitable for exponential interpolation (for

example, a negative value is subject to ln).

5063 IS NOT PRESET AFTER REF. This message is output when the position counter has not been

preset before the start of plate thickness measurement. This alarm is

issued in one of the cases below.

1) When an attempt was made to perform measurement before a refer-

ence position had been established.

2) When, after manual reference position return, an attempt was made

to start measurement without first setting the position counter.

5064 DIFFERRENT AXIS UNIT

(IS–B, IS–C)

Circular interpolation was specified for a plane formed by axes using

different increment systems.

5065 DIFFERRENT AXIS UNIT

(PMC AXIS)

In PMC–based axis control, axes using different increment systems

are specified for the same DI/DO group. Modify parameter No. 8010.

5066 RESTART ILLEGAL SEQUENCE

NUMBER

During program restart using the return/restart function, a sequence

number between 7000 and 7999 was read while performing search

for the next sequence number.

5068 G31 P90 FORMAT ERROR No axis is specified for movement.

Two or more axes were specified for movement.

5069 WHL–C; ILLEGAL P–DATA The P data, specified for selecting the compensation center for grind-

ing wheel wear compensation, is invalid.

5073 NO DECIMAL POINT A decimal point is not specified for a command for which a decimal

point must be specified.

5074 ADDRESS DUPLICATION ERROR The same address appears more than once in a block. Alternatively,

a block contains two or more G codes belonging to the same group.

5082 DATA SERVER ERROR Details are displayed on the data server message screen.

5085 SMOOTH IPL ERROR 1 A block for specifying smooth interpolation contains a syntax error.

5110 IMPROPER G–CODE

(G05.1 G1 MODE)

An illegal G code was specified in simple high–precision contour control

mode.

A command was specified for the index table indexing axis in simple

high–precision contour control mode.

5111 IMPROPER MODAL G–CODE

(G05.1 G1)

An illegal G code is left modal when simple high–precision contour con-

trol mode was specified.

5112 G08 CAN NOT BE COMMANDED

(G05.1 G1)

Look–ahead control (G08) was specified in simple high–precision con-

tour control mode.

5113 CAN NOT ERROR IN MDI MODE

(G05.1)

Simple high–precision contour control (G05.1) was specified in MDI

mode.

5114 NOT STOP POSITION

(G05.1 Q1)

At the time of restart after manual intervention, the coordinates at which

the manual intervention occurred have not been restored.
