Series 16i/160i-LA Operators manual Page 408

Operators manual

Page of 820

/ 820

OPERATION

B–63194EN/02

1. GENERAL

389

Proces-

sing pro-

file

Processing path of the second nozzle (beam)

Processing path of the first nozzle (beam)

Offset value for the first nozzle (beam)

Offset value for the second nozzle (beam)

Fig. 1.6 (c) Offset Values

Aside from parameters, data is set by the operator during machine

operation as required to change the machine characteristics.

For example, the following data can be set:

 Inch/metric conversion

 Data related to I/O devices

 Mirror image processing on/off

The above data is referred to as the settings. (See Section III–11.4.2.)

Setting

Screen Keys

MDI

Display

CNC memory

Program

Automatic

operation

Movement of

the machine

Operating

characteristics

Settings

Inch/metric conversion

I/O device data

Mirror image processing on/off

Fig. 1.6 (d) Displaying and Setting Settings

D Displaying and setting

settings
