OPERATION12. GRAPHICS FUNCTION

B–63194EN/02

694

Set interval of animated simulation drawing ranging from 0 to 255.

Every time the machining proceeds by the number set, the drawing is

repeated. If 0 is set, drawing is repeated at every 1 block execution.

Soft key Function

[A.ST] Simulate and draw the progress of machining.

[F.ST]

No figure during machining is drawn and only the final

finish figure by that program is drawn.

[STOP]

When pressed, stops drawing at the end of block (single

block stop).

[REWIND]

Press this key to perform drawing from the head of part

program. Heading is performed automatically after execu-

tion of program end (M02/M30).

No part program which has not been registered in memory can be drawn.

It is also necessary that the M02 or M30 be commanded at the end of the

part program.

It is possible to specify

BLANK FORM and BEAM FORM in the part

program. The command format is as shown below. If it is commanded

during execution of drawing, the item corresponding to the screen of

“

SOLID GRAPHIC (PARAMETER)” is set and drawing continues with the

set data.

S Command of

BLANK FORM

G10 L90 P_X_Y_Z_I_J_K_ ;

The command value succeeding the address is the same as the

numeric set to the address being displayed at the item of

BLANK

FORM of “SOLID GRAPHIC (PARAMETER)”. If BLANK FORM

is commanded, drawing continues after a new blank figure is

drawn.

S Command of BEAM FORM

G10 L91 P_R_K_ ;

The command value succeeding the address is the same as the

numeric set to the address being displayed at the item of

BEAM

FORM of screen “SOLID GRAPHIC (PARAMETER)”. If 0 is

commanded with the beam radius value, no machining simulation

is performed thereafter.

Parameter 6500 (DPO, bit 5) is used to specify whether to display the

coordinates of the current position on

SOLID GRAPHIC screen.

Parameter 6501 (3PL, bit 2) is used to select whether to draw a triplane

view with the third–angle or first–angle projection.

Parameter 6501 (RID, bit 3) is used to specify whether to draw ridges in

plane view drawing.

Parameter 6501 (FIM, bit 4) is used to specify whether to display a solid

graphics in the rough mode or in the fine mode. When a solid graphics

is drawn in the fine mode, the drawing speed is slower than when drawn

in the rough mode.

In triplane drawing, a value can be specified for changing the position of

the cross section while the soft key is held down. A value from 0 to 10

can be set. When 0 is specified, a value of 1 is used. (Parameter No. 6515)

D ANIM. SPEED

D Soft key functions on the

“SOLID GRAPHIC

(EXECUTION)”screen

D Graphics program

D Specifying the blank

form and beam form in

the part program

D Display of the coordinate

value

D Graphic method

D Ridge drawing

D Display mode

D Cross section position

change
