4. AUTOMATIC OPERATION
B–63194EN/02
476
The following table indicates the relation between other functions and the
movement by handle interrupt.
Display Relation
Machine lock Machine lock is effective. The nozzle does not move
even when this signal turns on.
Interlock Interlock is effective. The nozzle does not move even
when this signal turns on.
Mirror image Mirror image is not effective. Interrupt functions on the
plus direction by plus direction command, even if this
signal turns on.
The following table shows the relation between various position display
data and the movement by handle interrupt.
Display Relation
Absolute
coordinate value
Handle interruption does not change absolute coordi-
nates.
Relative
coordinate value
Handle interruption does not change relative coordinates.
Machine
coordinate value
Machine coordinates are changed by the travel distance
specified by handle interruption.
Press the function key
POS
, then press the chapter selection soft key
[HNDL].
The move amount by the handle interrupt is displayed. The following 4
kinds of data are displayed concurrently.
O0000 N02000
MDI
* * * *
* * * * * *
10 : 29 : 51
HANDLE INTERRUPTION
(INPUT UNIT)
(OUTPUT UNIT)
X 69.594 X 69.594
Y 137.783 Y 137.783
Z –61.439 Z –61.439
(RELATIVE)
X 0.000 X 0.000
Y 0.000 Y 0.000
Z 0.000 Z 0.000
(DISTANCE TO GO)
PART COUNT 287
RUN TIME 1H 12M CYCLE TIME 0H 0M 0S
ABS
REL ALL (OPRT)
HNDL
(a) INPUT UNIT : Handle interrupt move amount in input unit
system
Indicates the travel distance specified by handle
interruption according to the least input
increment.
(b) OUTPUT UNI : Handle interrupt move amount in output unit
system
Indicates the travel distance specified by handle
interruption according to the least command
increment.
Explanations
D Relation with other
functions
D Position display
D Travel distance display
