Series 0i-PC Operators manual Page 321

Operators manual

Page of 724

/ 724

PROGRAMMING

B–64154EN/01

18. AXIS CONTROL FUNCTIONS

297

X, Y and T or X, Y and C when automatic operation.

Least input increment IS-A : 0.01 deg, IS-B : 0.001 deg

Least command increment IS-A : 0.01 deg, IS-B : 0.001 deg

IS-A : "999999.99 deg

IS-B : "99999.999 deg

Linear acceleration/deceleration is possible in manual and automatic

rapid traverse rate.

Specifications are the same as X, Y and T axes.

The C-axis command is always regarded as absolute regardless of

designation of absolute command (G90) and incremental command

(G91).

However, parameter No. 16363#0 can also be used to enable the G91

command.

When the C-axis command is designated, it is possible to automatically

position the C axis from the present position to the commanded position

in the smaller angle rotating direction. When the rotation angle is 180

deg, positioning occurs in the forward direction (CW or CCW according

to the connections on the machine side) .

18.2.1

Simultaneously

Controlled Axes

18.2.2

Increment System

18.2.3

Maximum

Programmable

Dimension

18.2.4

Automatic

Acceleration/

Deceleration

18.2.5

Manual Continuous

Feed, Incremental

Feed, Manual

Reference Point Return

18.2.6

Relationship with

Absolute/Incremental

Command (G90/G91)

18.2.7

Positioning in Smaller

Angle Rotating

Direction
