PROGRAMMING

B–64154EN/01

5. FEED FUNCTIONS

In the automatic operation, the rapid traverse override is applied to the

rapid traverse rate by the switch on the machine operator’s panel or

F1-digit command (See Subsection 5.2.3).

Either rapid traverse override being set by the switch on the machine

operator’s panel or rapid traverse override being set by F1-digit

command, whichever is lower, becomes effective.

One digit

F command

Rapid traverse override switch on

machine operator’s panel

X-axis,

Y-axis

T-axis,

C-axis

F1 100% 100% 100%

F2 75% 75% 100%

F3 50%

50%

25%

50%

If F3 command is given when the switch on the machine operator’s panel

is set to 100%, the rapid traverse override of the X and Y axes becomes

50%, and also that of T-axis and C axis becomes 50%.

If F1 command is given when the switch on the machine operator’s panel

is set to 25%, the rapid traverse override of the X and Y axes becomes

25%, while that of T-axis and C axis becomes 50%.

In manual operation mode, the rapid traverse override by the switch on

the machine operator’s panel and by one-digit F command is ineffective.

WARNING

For the T-axis and C axis, the rapid traverse override can

always be set to 100% by setting a parameter TCO (No.

16052#1).

5.2.2

Rapid Traverse

Override

Examples1

Examples2
