OPERATION

B–64154EN/01

11. SETTING AND DISPLAYING DATA

575

5 For absolute programming, enter the data and press the [INPUT]

soft key.

For incremental programming, enter an increment or decrement

and press the [+INPUT] soft key.

Data items to be entered are as follows:

(a) Tool number

Specify the numbers of tools to be used. Up to 136 numbers can be

entered. Settings range from 0 to 9999.

(b)Turret position

When T-axis control is specified (TCL, bit 4 of parameter No. 16260,

is set to 1), specify the positions at which the turret is indexed for tools.

Settings range from 0 to 99999999.

When the tool position compensation function is used (TOF, bit 2 of

parameter No. 16263 is set to 1), specify X-axis offset for tool

positions in the machine coordinate system. Settings range from

–99999999 to +99999999.

(d)Y-axis offset

When the tool position compensation function is usedspecify Y-axis

offset for tool positions in the machine coordinate system. Settings

range from –99999999 to +99999999.

CAUTION

The X- and Y-axis offset must be 0 for the tool to be initially

selected, described in Item 11.4.3.1.
