Series 0i-PC Operators manual Page 577

Operators manual

Page of 724

/ 724

OPERATION

B–64154EN/01

11. SETTING AND DISPLAYING DATA

553

The reading on the load meter can be displayed for each servo axis by

setting bit 5 (OPM) of parameter 3111 to 1.

Procedure for displaying the operating monitor

1 Press function key

POS

to display a current position display screen.

2 Press the continuous–menu key

3 Press soft key

[MONI].

X : * * * 80% S1 : 201%

Y : * * * * * 0% (SPEED METER RPM)

C : * * * * * 0% S1 : * * * 1500

OPERATING MONITOR O0001 N00001

(LOAD METER)

[

MEM STRT MTN *** 09:06:35

[ ABS ][ REL ][ ALL ][ HNDL ][ OPRT ]

PART COUNT 5

RUN TIME 0H15M CYCLE TIME 0H 0M38S

ACT.F 3000 MM/M

The reading on the load meter can be displayed for up to three servo axes

by setting parameters 3151 to 3153.

The bar graph for the load meter shows load up to 200% (only a value is

displayed for load exceeding 200%).

The reading on the load meter depends on servo parameter 2086.

If the value of a load meter exceeds 100%, the bar graph turns purple.

11.1.7

Operating Monitor

Display

Procedure

Explanations

D Display of the servo axes

D Unit of graph

D Load meter

D Color of graph
