PROGRAMMING

19. HIGH SPEED CUTTING

FUNCTIONS

B–64154EN/01

308

This function is designed for high–speed precise machining. With this

function, the delay due to acceleration/deceleration and the delay in the

servo system which increase as the feedrate becomes higher can be

suppressed.

The tool can then follow specified values accurately and errors in the

machining profile can be reduced.

This function becomes effective when advanced preview control mode is

entered.

For details, refer to the relevant manual published by the machine tool

builder.

P1 : Turn on advanced preview control mode.

P0 : Turn off advanced preview control mode.

G08 P_

In advanced preview control mode, the following functions are available:

(1) Linear acceleration/deceleration before interpolation

(2) Automatic corner deceleration function

For details on the above functions, see the descriptions of the functions.

For functions

(1) and (2), specific parameters are provided.

Advanced preview control mode is canceled by reset.

Specify G08 code only in a block on the interpolation mode.

In the advanced preview control mode, the optional functions listed below

can be specified.

It cannot be used for the function to specify punching.

NOTE

To use a function other than the following optional functions,

turn the advanced preview control mode off, specify the

desired function, then turn the mode on again.

19.2

ADVANCED

PREVIEW CONTROL

(G08)

Format

Explanations

D Available functions

D Reset

Limitations

D G08 command

D Functions that can be

specified
