PROGRAMMING 2. CONTROLLED AXES

B–64154EN/01

Item 0i–PC

No. of basic controlled axes 3 axes

Controlled axes expansion (total) Max. 4 axes

Basic simultaneously controlled axes 2 axes

Simultaneously controlled axes expansion Max. 4 axes

The names of the two basic axes are fixed to X and Y, while the names of

additional axes can be set to any of A, B, C, U, V, W, and T.

Parameter No. 1020 is used to determine the name of each axis.

When this parameter is set to 0 or a character other than the valid

characters is specified, an axis name from 1 to 4 is assigned by default.

When a default axis name (1 to 4) is used, operation in the MEM mode,

MDI mode and RMT mode is disabled.

If a duplicate axis name is specified in the parameter, operation is enabled

only for the axis specified first.

If A, B, U, V and W is specified an axis name, the punch press macro

function is not available.

Name of

increment

system

Least input

increment

Least command

increment

Maximum

stroke

IS–A

0.01mm

0.001inch

0.01deg

0.01mm

0.001inch

0.01deg

999999.99mm

99999.999inch

999999.99deg

IS–B

0.001mm

0.0001inch

0.001deg

0.001mm

0.0001inch

0.001deg

99999.999mm

9999.9999inch

99999.999deg

Combined use of the inch system and the metric system is not allowed.

There are functions that cannot be used between axes with different unit

systems (circular interpolation, cutter compensation, etc.). For the

increment system, see the machine tool builder’s manual.

2.1

CONTROLLED AXES

2.2

AXIS NAME

Limitations

D Default axis name

D Duplicate axis names

2.3

INCREMENT SYSTEM
