Series 0i/0i Mate - Model B Parameter manual Page 119

Parameter manual

Page of 346

/ 346

B–63840EN/03

4. DESCRIPTION OF PARAMETERS

111

MS0, MS1 A combination of the number of characters preserved as external operator

message history data and the number of history data items is set according

to the table below.

MS1 MS0

Number of history

data characters

Number of history

data items

0 0 255 8

0 1 200 10

1 0 100 18

1 1 50 32

NOTE

When the values of MS0 and MS1 are changed, all preserved

external operator message history data is cleared.

3114

ICS

IUS

IMS

ISY

IOF

IPR

IPO

[Data type] Bit

IPO When the

POS

function key is pressed while the position display screen

is being displayed:

0 : The screen is changed.

1 : The screen is not changed.

IPR When the

PROG

function key is pressed while the program screen is being

displayed:

0 : The screen is changed.

1 : The screen is not changed.

IOF When the

OFFSET

SETTING

function key is pressed while the offset/setting screen is

being displayed:

0 : The screen is changed.

1 : The screen is not changed.

ISY When the

SYSTEM

function key is pressed while the system screen is being

displayed:

0 : The screen is changed.

1 : The screen is not changed.

IMS When the

MESSAGE

function key is pressed while the message screen is being

displayed:

0 : The screen is changed.

1 : The screen is not changed.

IUS When the

CUSTOM

GRAPH

(using the small MDI) or

GRAPH

(using the standard MDI)

function key is pressed while the custom or graphic screen is being

displayed:

0 : The screen is changed.

1 : The screen is not changed.
