B–63840EN/03

4. DESCRIPTION OF PARAMETERS

1730

Maximum feedrate for arc radius R

[Data type] Word

[Unit of data]

Increment system

Unit of data

Valid data range

ncremen

sys

IS-A, IS-B IS-C

Millimeter machine 1 mm/min 8 to 15000 0 to 12000

Inch machine 0.1 inch/min 8 to 6000 0 to 4800

Set a maximum feedrate for the arc radius set in parameter No.1731. Set

this parameter when the arc radius–based feedrate clamping function is

enabled.

1731

Arc radius value corresponding to a maximum feedrate

[Data type] 2–word

[Unit of data]

Unit IS–A IS–B IS–C Unit

Linear axis

(millimeter machine)

0.01 0.001 0.0001 mm

Linear axis

(inch machine)

0.001 0.0001 0.00001 inch

[Valid data range] 1000 to 99999999

Set the arc radius corresponding to the maximum feedrate set in parameter

No.1730. Set this parameter when the arc radius–based feedrate clamping

function is enabled.

1732

Minimum value (RV min) for arc radius–based feedrate clamp

[Data type] Word

Increment system

Unit of data

Valid data range

Increment s

stem

Unit of data

IS-A, IS-B IS-C

Millimeter machine 1 mm/min 0 to 15000 0 to 12000

Inch machine 0.1 inch/min 0 to 6000 0 to 4800

The arc radius–based feedrate clamping function reduces the maximum

feedrate as the arc radius decreases. When the specified maximum

feedrate is not greater than RV min (minimum value for arc radius–based

feedrate clamping), RV min is used as the maximum feedrate.

1762

Exponential acceleration/deceleration time constant for cutting feed in the ad-

vanced preview control mode

[Data type] Word axis

[Unit of data] 1 ms

[Valid data range] 0 to 4000

Set an exponential acceleration/deceleration time constant for cutting

feed in the advanced preview control mode.
