4. DESCRIPTION OF PARAMETERS

B–63840EN/03

116

These parameters set the axis name for current position display.

When G code system B or C is used, the axis name set in parameter

No.3132 is used for both absolute and relative coordinate axes.

The values set in these parameters are used only for display. For a

command address, the axis name set in parameter No.1020 is used.

When 0 is specified in these parameters, the value set in parameter

No.1020 is used.

3134 Axis display order on workpiece coordinate system screen and workpiece shift screen

[Data type] Byte axis

[Valid data range] 0, 1 to the number of controlled axes

This parameter specifies the order in which axes are displayed on the

workpiece coordinate system screen and workpiece shift screen (for T

series).

When the parameters of all axes are set to 0, all axes are displayed.

When the parameters of some axes are set, the axes for which a value of 0

is specified do not appear. The displayed axes are consecutive without

spaces being left for non–displayed axes.

3151 Number of the axis for which the first load meter for the servo motor is used

3152 Number of the axis for which the second load meter for the servo motor is used

3153 Number of the axis for which the third load meter for the servo motor is used

3154 Number of the axis for which the fourth load meter for servo motor is used

[Data type] Byte

[Valid data range] 0, 1, . . . , the number of control axes

Set the numbers of the axes for which measurement values on the load

meters for the fourth servo motors are displayed. Set the parameters to 0

for those axes for which a load meter need not be displayed.

3163 Time required to smooth the spindle load meter readings

[Data type] Byte

[Unit of data] 32 ms

[Valid data range] 0 to 32

When the spindle load meter reading is displayed (see the description of

the SLM parameter (bit 6 of parameter No.3108)), smoothing can be

applied to the spindle load meter reading to prevent flickering. This

parameter sets the time width for smoothing.

Setting Time for smoothing (msec)

0 256

1 32

2 64

3 96

: :

32 1024
