4. DESCRIPTION OF PARAMETERS

239

NOTE

This bit is invalid when bit 0 (NOP) of parameter No. 6000 is

set to 1. (M series)

SBV Custom macro statement

0 : Not stop the single block

1 : Stops the single block

To control single blocks in custom macro statements using system

variable #3003, use this parameter to enable or disable single blocks in

custom macro statements.

This bit is valid when bit 5 (SBM) of parameter No. 6000 is set to 0.

CLV6001

CCV

TCS

CRO

PV5

#2 #1

PRT

[Data type] Bit

PRT Reading zero when data is output using a DPRINT command

0 : Outputs a space

1 : Outputs no data

PV5 Custom macro common variables:

0 : Nos. 500 to 599 are output.

1 : Nos. 100 to 199 and Nos. 500 to 599 are output.

CRO ISO code in BPRWT or DPRNT commond

0 : Outputs only LF after data is output

1 : Outputs LF and CR after data is output

TCS Subprogram

0 : Not called using a T code

1 : Called using a T code

CCV Custom macro’s common variables Nos. 100 through 199

0: Cleared to “vacant” by reset

1: Not cleared by reset

CLV Custom macro’s local variables Nos. 1 through 33

0: Cleared to “vacant” by reset

1: Not cleared by reset
