Series 0i/0i Mate - Model B Parameter manual Page 71

Parameter manual
B–63840EN/03
4. DESCRIPTION OF PARAMETERS
63
NOTE
1 FAD (fine acceleration/deceleration) cannot be applied to
the spindles. When serial spindle advanced preview control
is applied, therefore, FAD cannot be used for the servo axes.
2 Advanced preview control is valid only for the first spindle.
Second spindle does not applied to advanced preview
control.
LS2 Acceleration/deceleration after interpolation for cutting feed in advanced
preview control mode is:
0 : Exponential acceleration/deceleration.
1 : Linear acceleration/deceleration.
#7
1603
#6
RBL
#5 #4
RPT
RPT
#3 #2 #1 #0
[Data type] Bit
RPT The acceleration/deceleration of interpolation–type rapid traverse is
performed:
0: With a constant inclination.
1: With a constant time.
NOTE
This parameter is invalid if the function of bell–shaped
acceleration/deceleration after rapid–traverse
interpolation is provided. The acceleration/deceleration
time constant and override for rapid traverse are used.
RBL In the AI advanced preview control/AI contonr control mode,
acceleration/deceleration of rapid traverse is:
0: Linear acceleration/deceleration.
1: Bell–shaped acceleration/deceleration.
NOTE
Bit 4 (RPT) of parameter No. 1603 is invalid.
#7
1610
#6 #5 #4
JGLx
#3 #2 #1 #0
CTLx
[Data type] Bit axis
CTLx Acceleration/deceleration in cutting feed including feed in dry run
0 : Exponential acceleration/deceleration is applied.
1 : Linear acceleration/deceleration after interpolation is applied.
JGLx Acceleration/deceleration in jog feed
0 : Exponential acceleration/deceleration is applied.
1 : Linear acceleration/deceleration after interpolation or bell–shaped
acceleration/deceleration after interpolation is applied.
