4. DESCRIPTION OF PARAMETERS

B–63840EN/03

Specify the maximum cutting feedrate for each axis in the AI advanced

preview control/AI contonr control mode, or advanced preview control

mode.

A feedrate for each axis is clamped during cutting feed so that it does not

exceed the maximum cutting feedrate specified for each axis.

NOTE

1 This parameter is effective only in linear and circular

interpolation during advanced preview control mode. In

cylindrical interpolation, the maximum feedrate for all axes

specified in parameter No.1431 is effective.

2 If a setting for each axis is 0, the maximum feedrate specified

in parameter No.1431 is applied to all axes and the feedrate

is clamped at the maximum feedrate during advanced

preview control mode.

3 The maximum cutting feedrate in the AI advanced preview

control/AI contour control mode is the lowest value of

parameters No.1432, No.1422, and No.1420. When one of

these parameters is set to 0, however, alarm No.5157 is

applied.

4 In a mode other than the AI advanced preview control mode

or advanced preview control/AI contour control mode, the

maximum cutting feedrate specified in parameter No.1422

or No.1430 is applied and the feedrate is clamped at the

maximum feedrate.

1450

Change of feedrate for one graduation on the manual pulse generator during F1

digit feed

[Data type] Byte

[Valid data range] 1 to 127

Set the constant that determines the change in feedrate as the manual pulse

generator is rotated one graduation during F1-digit feed.

F +

Fmaxi

100n

∆

(where, i=1 or 2)

In the above equation, set n. That is, the number of revolutions of the

manual pulse generator, required to reach feedrate Fmaxi is obtained.

Fmaxi refers to the upper limit of the feedrate for an F1-digit feed

command, and set it in parameter 1460 or 1461.

Fmax1: Upper limit of the feedrate for F1 to F4 (parameter 1460)

Fmax2: Upper limit of the feedrate for F5 to F9 (parameter 1461)
