Series 0i/0i Mate - Model B Parameter manual Page 85

Parameter manual

Page of 346

/ 346

B–63840EN/03

4. DESCRIPTION OF PARAMETERS

CIN When bit 4 (CCI) of parameter No.1801 = 1, the in–position area for

cutting feed is:

0 : Use value in parameter No.1827 if the next block is also for cutting

feed, or use value in parameter No.1826 if the next block is not for

cutting feed.

1 : Use value in parameter No.1827, regardless of the next block. (The

setting of parameter No.1826 is used for rapid traverse, and the setting

of parameter No.1827 is used for cutting feed.)

1802

#6 #5

DPS

B15

#3 #2 #1 #0

CTS

FWC

NOTE

After this parameter is set, the power needs to be turned off.

[Data type] Bit

CTS The servo motor–based speed control function is:

0 : Not used

1 : Used

B15 In backlash compensation, the travel direction is determined:

0: Without consideration of the compensation amount (pitch error,

external machine coordinate shift, etc.).

1: In consideration of the compensation amount. (FS15 format)

DPS When servo motor–based speed control is applied, a position coder is:

0 : Used

1 : Not used

FWC The processing of command multiplication (CMR) is performed:

0: After acceleration/deceleration after interpolation.

1: Before acceleration/deceleration after interpolation.

1803

#6 #5 #4

TQF

#3 #2 #1

TQA

TQI

[Data type] Bit

TQI While torque restriction is applied, in–position check is:

0 : Performed.

1 : Not performed.

TQA While torque restriction is applied, checking for an excessive error in the

stopped state/during movement is:

0 : Performed.

1 : Not performed.

TQF When torque control is performed by an axis control command of the

PMC axis control function, follow–up operation is:

0 : Not performed.

1 : Performed.
