Series 0i/0i Mate - Model B Parameter manual Page 75

Parameter manual

Page of 346

/ 346

B–63840EN/03

4. DESCRIPTION OF PARAMETERS

1624

Time constant of exponential acceleration/deceleration or bell–shaped accelera-

tion/deceleration or linear acceleration/deceleration after interpolation, in jog

feed for each axis.

[Data type] Word axis

[Unit of data] ms

[Valid data range] 0 to 4000(exponential acceleration/deceleration in jog feed)

0 to 512 (linear acceleration/deceleration after interpolation in jog feed)

Set the time constant used for exponential acceleration/deceleration or

linear acceleration/deceleration after interpolation in jog feed fot each

axis. The type to select depends on the settings of the parameters CTLx,

and JGLx (Nos. 1610#0 and #4).

1625 FL rate of exponential acceleration/deceleration in jog feed for each axis.

[Data type] Word axis

[Unit of data]

[Valid data range]

Increment system

Unit of data

Valid data range

ncremen

sys

IS-A, IS-B IS-C

Millimeter machine 1 mm/min 6 to 15000 6 to 12000

Inch machine 0.1 inch/min 6 to 6000 6 to 4800

Rotaion axis 1 deg/min 6 to 15000 6 to 12000

Set the lower limit (FL rate) of exponential acceleration/deceleration in

cutting feed for each axis.

1626

Time constant of exponetial acceleration/deceleration in the thread cutting cycle

for each axis

[Data type] Word axis

[Unit of data] ms

[Valid data range] 0 to 4000

Set the time constant used for exponential acceleration/deceleration in the

thread cutting cycle (G76, G92 (G78 in G code system B/C)) for each axis.

If the acceleration type is not exponential acceleration/deceleration,

parameter No. 1622 becomes valid.
