4. DESCRIPTION OF PARAMETERS

B–63840EN/03

1620

Time constant T or T

used for linear acceleration/deceleration or bell–shaped

acceleration/deceleration in rapid traverse for each axis

[Data type] Word axis

[Unit of data] ms

[Valid data range] 0 to 4000

Specify a time constant used for acceleration/deceleration in rapid tra-

verse. When the optional function of bell–shaped acceleration/decelera-

tion in rapid traverse is provided, bell–shaped acceleration/deceleration is

applied in rapid traverse. If the function is not provided, linear accelera-

tion/deceleration is applied.

(1) When the function is provided, set this parameter to time constant T

used in bell–shaped acceleration/deceleration in rapid traverse, and

set parameter No.1621 to time constant T

(2) When the function is not provided, specify a time constant used in

linear acceleration/deceleration.

NOTE

1 When parameter No.1621 (time constant T

used for

bell–shaped acceleration/deceleration in rapid traverse) is

set to 0, linear acceleration/deceleration is applied in rapid

traverse even if the function is provided. In this case, this

parameter stands for a time constant used in linear

acceleration/deceleration in rapid traverse.

2 Depending on the setting value of the time constant, the rate

slightly lower than the rapid traverse rate may be applied for

a given period of time while reaching the rapid traverse rate

after acceleration. To work around this problem, set a

multiple of 8 as the time constant.
