4. DESCRIPTION OF PARAMETERS

B–63840EN/03

158

3811

Maximum spindle speed for gear 1 of the second spindle

3812

Maximum spindle speed for gear 2 of the second spindle

[Data type] Word

[Unit of data] min

–1

[Valid data range] 0 to 32767

Set the maximum spindle speed for each gear of the second spindle.

NOTE

These parameters are used for the multi–spindle control.

3820

Data for adjusting the gain of the analog output of the third–spindle speed

[Data type] Word

[Unit of data] 0.1%

[Valid data range] 700 to 1250

Set the data used for adjusting the gain of the analog output of the third

spindle speed.

NOTE

This parameter is used for controlling the multi–spindles.

3821

Offset–voltage compensation value of the analog output of the third–spindle speed

[Data type] Word

[Unit of data] Velo

[Valid data range] –1024 to 1024

Set the offset–voltage compensation value of the analog output of the

third–spindle speed.

NOTE

This parameter is used for controlling the multi–spindles.
