4. DESCRIPTION OF PARAMETERS

B–63840EN/03

G52 In local coordinate system setting (G52), a cutter compensation vector is:

0 : Not considered.

1 : Considered.

NOTE

Select a local coordinate system setting operation when

cutter compensation is applied, and when two or more

blocks specifying no movement exist prior to the

specification of G52, or when G52 is specified after cutter

compensation mode is canceled without eliminating the

offset vector.

1203

#6 #5 #4 #3 #2 #1 #0

EMC

[Data type] Bit

EMC The extended external machine zero point shift function is:

0: Disabled.

1: Enabled.

NOTE

1 To use the extended external machine zero point shift

function, the external machine zero point shift function or the

external data input function is required.

2 When the extended machine zero point shift function is

enabled, the conventional external machine zero point shift

function is disabled.

1220 External workpiece zero point offset value

[Data type] 2–word axis

[Unit of data]

Input increment IS–A IS–B IS–C Unit

Linear axis (input in mm) 0.01 0.001 0.0001

Linear axis (input in inches) 0.001 0.0001 0.00001 inch

Rotation axis 0.01 0.001 0.0001 deg

[Valid data range] –99999999 to 99999999

This is one of the parameters that give the position of the origin of

workpiece coordinate system (G54 to G59). It gives an offset of the

workpiece origin common to all workpiece coordinate systems. In

general, the offset varies depending on the workpiece coordinate systems.

The value can be set from the PMC using the external data input function.
