Open CNC Screen Display Function Operators manual Page 33

Operators manual
B-63164EN/04 2.OPERATION
- 17 -
(1) CNC number
The number of a CNC that can be connected is indicated.
(2) CNC model
The model of the CNC that is connected or which can be
connected is indicated.
(3) Connection status
Disconnect :
The power to the CNC is off, or the cable is not
connected correctly.
In this state, neither the
button nor
button can be choosed.
Connecting :
The CNC is connected correctly.
Choosing the
button executes the
CNC screen display function.
The
button cannot be choosed.
Executing :
The CNC screen display function is running.
Choosing the
button displays the
currently executed CNC screen on top.
Choosing the
button stops the CNC
screen display function. When this button is choosed,
the connection status in the list changes from
Executing to Connecting.
NOTE
When a CNC in the Disconnect status has been
connected correctly, perform the following
operation. Then, the status indication changes to
Connecting, and the button can be
choosed.
Q With the mouse, click an arbitrary CNC in the
list.
R With the cursor keys, select another item in the
list.
The CNC to be connected can be specified using an
argument on the command line. When this argument is
used, the above Select CNC screen does not appear.
The format of the command line specification is as
follows:
CNCSCRN /NODE = <CNC-number>
