Open CNC Screen Display Function Operators manual Page 35

Operators manual
B-63164EN/04 2.OPERATION
- 19 -
l When the MDI keyboard type of the FS160i/180i/210i with
the personal computer or the MDI keyboard type of the
FS160i/180i/210i/150i with a CNC Display Unit with
Personal Computer Function are used
Press the unlabeled key (or [FAPT])+[SHIFT]+[DELETE].
NOTE
During the termination processing for the CNC
screen display function, the following message
appears:
If the CNC screen display function is restarted while
this message is being displayed, the CNC screen
display function may operate abnormally. When
restarting the CNC screen display function, restart
the function after the above message disappears.
