B-62924EN/04 SUPPLEMENT C.SETTING USING A PERSONAL COMPUTER

- 221 -

CAUTION

Pay careful attention to the following two points:

<1> For Softing PROFIBUS-DP Configurator, the

default TTR value is 50000. Change the TTR

value to 65000.

<2> Change the values of the following three

parameters on Screen C-14 only when the baud

rate is 12 Mbps:

- Min. St. Delay Resp. : 11 → 13

- Max. St. Delay : 800 → 802

- Quiet Time : 9 → 12

At this time, the values set for these three

parameters for the FANUC master station or

another master station on the network need not

be changed.

(10) Select Download, then Remote. Remote downloading starts.

The bus parameters and slave parameters are automatically

downloaded in this order.

CAUTION

Remote downloading overwrites the bus parameters

and slave parameters set on the FANUC master

station.

Setting for address assignment cannot be

performed with PROFIBUS-DP Configurator. After

completion of remote downloading, perform setting

for address assignment and turn the power off, then

on again.

General remote downloading operation is now complete.
