1.16i/18i/21i-A/B, Power Mate i-D/H, AND 16/18-C OPERATION B-62924EN/04

- 58 -

EndModule

Module = "24 Byte Out, 24 Byte In" 0xC0,0x17,0x17

EndModule

Module = "20 Byte Out, 20 Byte In" 0xC0,0x13,0x13

EndModule

Module = "16 Byte Out, 16 Byte In" 0xC0,0x0F,0x0F

EndModule

Module = "12 Byte Out, 12 Byte In" 0xC0,0x0B,0x0B

EndModule

Module = " 8 Byte Out, 8 Byte In" 0xC0,0x07,0x07

EndModule

Module = " 4 Byte Out, 4 Byte In" 0xC0,0x03,0x03

EndModule

Module = " 2 Byte Out, 2 Byte In" 0xC0,0x01,0x01

EndModule

Module = "32 Byte Out, 1 Byte In" 0xC0,0x1F,0x00

EndModule

Module = " 1 Byte Out, 32 Byte In" 0xC0,0x00,0x1F

EndModule

;

NOTE

For a FANUC slave station, the DI/DO sizes can be

changed without restrictions as long as the total of

the DI/DO sizes does not exceed 244 bytes. For

this reason, all of the values to be specified for

Module cannot be listed.

For the values to be specified for Module, see

Tables 1-12 to 1-14 in Section 1.4, "Setting the

Slave Parameters for Using a Slave Station

Manufactured by FANUC."
