FANUC Series 16i/160i-LB Processing Mode Change Function Additional Manual Page 11

Additional Manual
08
If the value obtained by multiplying the specified peak power value by the power
override value is greater than the value set in this parameter, the duty ratio is
clamped at 50% (fixed value), and the specified peak power value is clamped at
the value set in parameter No.29049. When 0 is specified, the value of parameter
No.29049 is assumed.
・Settings for alarm monitor
（Alarm No.4125）
#7 #6 #5 #4 #3 #2 #1 #0
15008 DCW
[Data type] Bit
DCW In diagnostic display, the values of DCV, DCI, and DCW are:
0: Not displayed.
1: Displayed.
This parameter is valid only for oscillators that support this display.
The name of this parameter is not displayed.
Note
Alarm No.4125 can’t be monitored when parameter No.15008#5 ,
No.29046 or No.29047 is zero. If alarm No.4125 is needed to be
monitored, set this parameter to 1 and set proper setting value to
No.29046 and No.29047.
29046 In-tube pressure to check gas spec.
[[Data type] Word
[Unit of data] (1=13Pa)
[Valid data range] 0～32767
In the laser oscillator start up sequence, alarm No.4125 happens if DCI value of
laser power supply is equal to or higher than parameter No.29047 when in-tube
pressure reaches this parameter value after HVON(G222#7)=1. Alarm No.4125
can’t be monitored if this parameter value is zero.
29047 DCI maximum value to check gas spec.
[[Data type] Word
[Unit of data] 0.1A
[Valid data range] 0～32767
In the laser oscillator start up sequence, alarm No.4125 happens if DCI value of
laser power supply is equal or higher than this parameter value when in-tube
Ed.
Apprv.Design
Date
Design
Descri
p
tion
Date
FANUC Series 16i /160i –LB
Processing mode change function
A
－90107E
Sep.17,2005
H.Tokito
11
/
19
Title
Draw
No.
Sheet
07
06
05
04
03
02
