FANUC Series 16i/160i-LB Processing Mode Change Function Additional Manual Page 12

Additional Manual
08
pressure reaches parameter No.29046 after HVON(G222#7)=1. Alarm No.4125
can’t be monitored if this parameter value is zero
・ Settings for automatic aging function
（Fine mode）
29060
Laser power in normal calibration（Fine mode）
[[Data type] Word
[Unit of data] W
[Valid data range] 0～7000
Set the power specified for obtaining the power calibration coefficient
Note
When manually performing the aging operation by changing the setting,
set the same value in parameter No.29060 and No.15201
29061
Oscillation frequency in normal calibration（Fine mode）
[[Data type] Word
[Unit of data] Hz
[Valid data range] 5～2000
Set the frequency specified for obtaining the power calibration coefficient.
Note
When manually performing the aging operation by changing the setting,
set the same value in parameter No.29061 and No.29072.
29062
Pulse duty ration in normal calibration（Fine mode）
[[Data type] Word
[Unit of data] %
[Valid data range] 0～100
Set the pulse duty specified for obtaining the power calibration coefficient.
Note
When manually performing the aging operation by changing the setting,
set the same value in parameter No.29062 and No.29073.
Ed.
Apprv.Design
Date
Design
Descri
p
tion
Date
FANUC Series 16i /160i –LB
Processing mode change function
A
－90107E
Sep.17,2005
H.Tokito
12
/
19
Title
Draw
No.
Sheet
07
06
05
04
03
02
