  2. FANUC Series 16i/160i-LB Processing Mode Change Function

FANUC Series 16i/160i-LB Processing Mode Change Function Additional Manual Page 18

Additional Manual
08
－ Automatic aging function execution signal
AGNG<F224#6>
[Classification] Output signal
[Function] This signal notifies the PMC that the automatic aging function is being executed.
[Operation] When automatic aging function is executed and the parameter of aging times
No.15334 that is set by CNC automatically is equal or larger than “1”, signal
AGNG is turned on.
－ Laser oscillator warm up function execution signal
WMUP<F488#7>
[Classification] Output signal
[Function] This signal notifies the PMC that the laser oscillator warm up function is being
executed.
[Operation] This signal becomes “1” when laser oscillator warm up function is executed. This
signal becomes “0” when warm up function is completed.
－ Processing mode signal
LGCG<F489#0>
[Classification] Output signal
[Function] This signal notifies the PMC that which processing mode is selected high power
mode or fine mode.
[Operation] When parameter No.29016#0=0, this signal becomes “0”. When parameter
No.29016#0=1, this signal becomes “1”.
・Signal address
#7 #6 #5 #4 #3 #2 #1 #0
G222 HVON RUN
#7 #6 #5 #4 #3 #2 #1 #0
F221 LSTR LRDY
#7 #6 #5 #4 #3 #2 #1 #0
F224 AGNG
#7 #6 #5 #4 #3 #2 #1 #0
F487 WMUP
#7 #6 #5 #4 #3 #2 #1 #0
F489 LGCG
