FANUC Series 16i/160i-LB Processing Mode Change Function Additional Manual Page 8

Additional Manual
08
29020
Power calibration coefficient（Fine mode）
[Data type] Word
[Unit of data]
[Valid data range] 0～32767
The coefficient is used to calibrate the specified power according to the actual
power. This parameter is automatically specified during power calibration.
29022
Bias value（Fine mode）
[[Data type] Word
[Unit of data] mV
[Valid data range] 0～32767
Specify a bias value.
29023
In-tube pressure during osillation (50Hz) （Fine mode）
[[Data type] Word
[Unit of data] (1=13Pa)
[Valid data range] 0～32767
The discharge tube has the gas pressure during laser oscillation (50Hz).
29024
In-tube pressure during osillation (60Hz) （Fine mode）
[[Data type] Word
[Unit of data] (1=13Pa)
[Valid data range] 0～32767
The discharge tube has the gas pressure during laser oscillation (60Hz).
29025
Normal discharge tube voltage（Fine mode）
[[Data type] Word
[Unit of data] V
[Valid data range] 0～32767
Specify a discharge tube voltage in normal reference discharge. This parameter is
automatically rewritten after the discharge start signal (G222#7/HVON) turned
“ON”.
Ed.
Apprv.Design
Date
Design
Descri
p
tion
Date
FANUC Series 16i /160i –LB
Processing mode change function
A
－90107E
Sep.17,2005
H.Tokito
8
/
19
Title
Draw
No.
Sheet
07
06
05
04
03
02
