FANUC Series 16i/160i-LB Processing Mode Change Function Additional Manual Page 13

Additional Manual
08
29063
Calibration time of normal calibration（Fine mode）
[[Data type] Word
[Unit of data] sec
[Valid data range] 0～32767
Set the time specified for obtaining the power calibration coefficient.
Note
When manually performing the aging operation by changing the setting,
set the same value in parameter No.29063 and No.15205.
29064
Gas pressure in normal calibration（５０Ｈｚ）（Fine mode）
[[Data type] Word
[Unit of data] (1=13Pa)
[Valid data range] 0～32767
Set the in-tube pressure to be set for oscillation during power calibration. For an
oscillator containing an inverter, set the same value as the setting of parameter
No.29065. (The value set when an oscillator containing no inverter is used in an
area using a supply frequency of 50Hz.)
Note
The gas pressure may have been changed in the field. So, input the
setting of parameters No.29023 and No.29024 in parameters No.29064
and No.29065.
29065
Gas pressure in normal calibration（６０Ｈｚ）（Fine mode）
[[Data type] Word
[Unit of data] (1=13Pa)
[Valid data range] 0～32767
Set the in-tube pressure to be set for oscillation during power calibration. For an
oscillator containing an inverter, set the same value as the setting of parameter
No.29064. (The value set when an oscillator containing no inverter is used in an
area using a supply frequency of 60Hz.)
Note
The gas pressure may have been changed in the field. So, input the
setting of parameters No.29023 and No.29024 in parameters No.29064
and No.29065.
Ed.
Apprv.Design
Date
Design
Descri
p
tion
Date
FANUC Series 16i /160i –LB
Processing mode change function
A
－90107E
Sep.17,2005
H.Tokito
13
/
19
Title
Draw
No.
Sheet
07
06
05
04
03
02
