FANUC Series 16i/160i-LB Processing Mode Change Function Additional Manual Page 3

Additional Manual
08
The parameters for Fine mode are newly added in automatic aging function as
follows.
Table 2 : Setting parameters for automatic aging function of each mode
Setting
Parameter
（High power mode）
Parameter
（Fine mode）
Laser power in normal calibration No.15320
No.29060
Oscillation freq. in normal calibration No.15321
No.29061
Pulse duty ration in normal calibration No.15322 No.29062
Calibration time of normal
calibration
No.15323 No.29063
Gas pressure in normal calibration
(50Hz)
No.15324 No.29064
Gas pressure in normal calibration
(60Hz)
No.15325 No.29065
Laser power in aging No.15326 No.29066
Oscillation freq. in aging No.15327 No.29067
Pulse duty ration in aging No.15328 No.29068
Calibration time in aging No.15329 No.29069
Gas pressure in aging (50Hz) No.15330 No.29070
Gas pressure in aging (60Hz) No.15331 No.29071
Pulse frequency in normal calibration No.15332 No.29072
Pulse duty ration in normal calibration No.15333 No.29073
Ed.
Apprv.Design
Date
Design
Descri
p
tion
Date
FANUC Series 16i /160i –LB
Processing mode change function
A
－90107E
Sep.17,2005
H.Tokito
3
/
19
Title
Draw
No.
Sheet
07
06
05
04
03
02
