oscillator containing no inverter is used in an area using a supply frequency of
50Hz.)
Note
The gas pressure may have been changed in the field. So, input the
values obtained by subtracting 100 from the settings of parameter
No.29023 and No.29024 in parameters No.29070 and No.29071.
29071
Gas pressure in aging（60Hz）（Fine mode）
[[Data type] Word
[Unit of data] (1=13Pa)
[Valid data range] 0～32767
Set the in-tube pressure to be set during oscillation when aging is performed by
the automatic aging function. (The value set when an oscillator containing an
inverter is used or when an oscillator containing no inverter is used in an area
using a supply frequency of 60Hz.)
Note
The gas pressure may have been changed in the field. So, input the
values obtained by subtracting 100 from the settings of parameter
No.29023 and No.29024 in parameters No.29070 and No.29071.
29072
Pulse frequency in normal calibration（Fine mode）
[[Data type] Word
[Unit of data] Hz
[Valid data range] 5～2000
Set the frequency specified for power calibration.
Note
When manually performing the aging operation by changing the setting,
set the same value in parameters No.29072 and No.29061.
29073
Pulse duty ration in normal calibration（Fine mode）
[[Data type] Word
[Unit of data] %
[Valid data range] 0～100
Set the pulse duty ration specified for power calibration.
Note
When manually performing the aging operation by changing the setting,
set the same value in parameters No.29073 and No.29062.
Ed.
Apprv.Design
Date
Design
Descri
p
tion
Date
FANUC Series 16i /160i –LB
Processing mode change function
A
－90107E
Sep.17,2005
H.Tokito
15
/
19
Title
Draw
No.
Sheet
07
06
05
04
03
02
Previous page
Next page
