FANUC Series 16i/160i-LB Processing Mode Change Function Additional Manual Page 9

Additional Manual
08
29026
Value 0 when half of the discharge tubes are used（Fine mode）
29027
Value 1 when half of the discharge tubes are used（Fine mode）
29028
Value 2 when half of the discharge tubes are used（Fine mode）
29029
Value 3 when half of the discharge tubes are used（Fine mode）
29030
Value 4 when half of the discharge tubes are used（Fine mode）
29031
Value 5 when half of the discharge tubes are used（Fine mode）
29032
Value 6 when half of the discharge tubes are used（Fine mode）
29033
Value 7 when half of the discharge tubes are used（Fine mode）
29034
Value 8 when half of the discharge tubes are used（Fine mode）
[[Data type] Word
[Unit of data] V
[Valid data range] 0～32767
Specify power setting 0 to 8 at the table intervals, in the indicated order, when
half of the discharge tubes are used. For the standard setting, refer to the sheet
attached to the laser oscillator.
29037
Value 0 when all of the discharge tubes are used（Fine mode）
29038
Value 1 when all of the discharge tubes are used（Fine mode）
29039
Value 2 when all of the discharge tubes are used（Fine mode）
29040
Value 3 when all of the discharge tubes are used（Fine mode）
29041
Value 4 when all of the discharge tubes are used（Fine mode）
29042
Value 5 when all of the discharge tubes are used（Fine mode）
29043
Value 6 when all of the discharge tubes are used（Fine mode）
29044
Value 7 when all of the discharge tubes are used（Fine mode）
29045
Value 8 when all of the discharge tubes are used（Fine mode）
Ed.
Apprv.Design
Date
Design
Descri
p
tion
Date
FANUC Series 16i /160i –LB
Processing mode change function
A
－90107E
Sep.17,2005
H.Tokito
9
/
19
Title
Draw
No.
Sheet
07
06
05
04
03
02
