Series 21i/210i-Model A Connection manual (Hardware) Page 120

Connection manual (Hardware)
B–63083EN/02
8. CONNECTING THE PC INTERFACE
107
(1)Recommended full keyboard
A86L–0001–0210: 101–key type
A86L–0001–0211: 106–key type
(2)Recommended mouse
A86L–0001–0212: Standard PS/2 mouse
NOTE
This interface and the recommended devices are
exclusively for applications development and maintenance.
However, their use is possible only when the
A02B–0236–C130#JC or A02B–0236–C130#EC FA full
keyboard is used as the full keyboard. In this case, clamp
the cable with a cable clamp at points as close as possible
to the connectors so that the weight of the cable is not
directly applied to connectors JD32A and JD32B.
