Series 21i/210i-Model A Connection manual (Hardware) Page 45

Connection manual (Hardware)

Page of 392

/ 392

B–63083EN/02

3. INSTALLATION

Group ActionSignal line

Cable between the CNC and servo

amplifier

Bind the cables in group C

separately from group A, or

cover grou

C with an

Cable for position and velocity

feedback

cover

grou

with

electromagnetic shield.

Separate group C as far from

Cable between the CNC and spindle

amplifier

Group B as possible.

Be sure to perfrom shield

rocessing in Subsec 3 6 5

Cable for the position coder

rocessing

Subsec

Cable for the manual pulse

generator

Cable between the CNC and the

CRT/MDI

RS–232C and RS–422 interface

cable

Cable for the battery

Other cables to be covered with the

shield

NOTE

1 The groups must be 10 cm or more apart from one another

when binding the cables in each group.

2 The electromagnetic shield refers to shielding between

groups with grounded steel plates.

3 The shield is not required when the cable between the CNC

and MDI is shorter than 30 cm.
