5. CONNECTION TO CNC PERIPHERALS

Signal

name

RS–232C

circuit

number

I/O Description

SD 103 Output Sending

data

Start bit Stop bit

RD 104 Input Receivin

data

OFF

(When ISO code “0” is sent)

123 8567

RS 105 Input Sending

request

This signal is set to on when NC starts

sending data and is turned off when

transmission ends.

CS 106 Input Sending

permitted

When both this signal and the DR

signal are set, the NC can send data. If

external device processing is delayed

by a punching operation, etc., NC data

sending can be stopped by turning off

this signal after sending two

characters, including the data being

sent currently. If this signal will not be

used, make sure to strap this signal

circuit to the RS signal circuit.

DR 107 Input Data set

ready

When external device is ready to

operate, this signal is set. This signal

should usually be connected to the

signal indicating external device power

supply being on. (ER signal of external

device). See Note below.

The NC transfers data when this signal

is set. If the signals turned off during

data transfer, alarm 086 is issued. If the

DR signal will not be used, make sure

to strap this signal circuit to the ER

signal circuit.

ER 108.2 Output NC ready

operation

This signal is set when the NC is ready

to operate. External device should

regard the SD signal as being

significant when the ER signal is set.

CD 109 Input Signal

quality

signal

Since this signal is not used in

connections with external device, the

signal circuit must be strapped, inside

the connecting cable, to the ER signal

circuit.

SG 102 Signal

grounding

FG 101 Frame

grounding

NOTE

Signal on/off state is defined as follows;

–3V or lower

Signal Condition

+3V or higher

Function

Marking

OFF

Spacing

Signal description of

RS–232C interface
