Series 21i/210i-Model A Connection manual (Hardware) Page 15

Connection manual (Hardware)
B–63083EN/02
1. CONFIGURATION
2
The following table lists the main differences between the types of
FANUC Series 21i/210i control units.
The figures on the subsequent pages show the configurations of the Series
21i/210i control units. The descriptions in this manual focus on how to
connect the units illustrated in these figures. Within the figures, the
numbers in parentheses correspond to the section references in the
manual.
Control
Unit Name
Option Slots Display Device
Remark
7.2″ STN monochrome LCD
Without o
p
tion slot
8.4″ TFT color LCD
Without
o tion
slot
9.5″ STN monochrome LCD
Series 21i
10.4″ TFT color LCD
control unit
7.2″ STN monochrome LCD
With o
p
tion 2 slots
8.4″ TFT color LCD
With
o tion
2
slots
9.5″ STN monochrome LCD
10.4″ TFT color LCD
7.2″ STN monochrome LCD Note 1)
With o
p
tion 2 slots
8.4″ TFT color LCD Note 1)
Series 210i
With
o tion
2
slots
9.5″ STN monochrome LCD Note 1)
control unit
10.4″ TFT color LCD Note 1)
Without option slot 10.4″ TFT color LCD Note 2)
With option 2 slots 10.4″ TFT color LCD Note 2)
NOTE
1 Model with HSSB option card for high–speed data
communication with a PC.
2 Model incorporating PC function in the control unit.
1.1
NAME OF EACH
PART OF CONTROL
UNIT
Previous page
Next page
