Series 21i/210i-Model A Connection manual (Hardware) Page 6

Connection manual (Hardware)
B–63083EN/02
PREFACE
p–3
The table below lists manuals related to the 21i–TA, 21i–MA, 210i–TA,
and 210i–MA. In the table, this manual is marked with an asterisk (*).
Manuals related to the Series 21i/210i
Manual name
Specification
number
DESCRIPTIONS B–63082EN
CONNECTION MANUAL (Hardware) B–63083EN
*
CONNECTION MANUAL (Function) B–63083EN–1
OPERATOR’S MANUAL (For Lathe) B–63084EN
OPERATOR’S MANUAL (For Machining Center) B–63094EN
MAINTENANCE MANUAL B–63085EN
PARAMETER MANUAL B–63090EN
PROGRAMMING MANUAL
(Macro Compiler / Macro Executer)
B–61803E–1
FAPT MACRO COMPILER PROGRAMMING MANUAL B–66102E
FANUC PMC–MODEL SA1/SA5 PROGRAMMING
MANUAL (Ladder)
B–61863E
FANUC PMC–MODEL SC/NB PROGRAMMING
MANUAL (C language)
B–61863E–1
FAPT LADDER–II OPERATOR’S MANUAL B–66184EN
FANUC Symbolic CAPi T OPERATOR’S MANUAL B–63304EN
FANUC Super CAPi T OPERATOR’S MANUAL B–63284EN
FANUC Symbolic CAP T OPERATOR’S MANUAL
(Basic Module V1)
B–62824EN
FANUC Symbolic CAP T OPERATOR’S MANUAL
(C/Y axis Module V1)
B–62824EN–1
FANUC Super CAPi M PROGRAMMING MANUAL B–63293EN
FANUC Super CAPi M OPERATOR’S MANUAL B–63294EN
 
