Series 21i/210i-Model A Connection manual (Hardware) Page 36

Connection manual (Hardware)
B–63083EN/02
3. INSTALLATION
23
3) The inside air may flow from top to bottom or bottom to top. However,
generally decide the direction as follows :
a) Bring in the air near high heat loss components.
b) Exhaust the air toward the most important components to be
cooled.
4) For the cooling fin to display the specified cooling capacity, the air inside
the cooling fins must flow at a velocity of 2.5 m/sec or greater.
(velocity of air flow measurement)
Set the slit to the intake side
and measure the velocity at
the slit.
5) Generally, install the cooling fins to the door. But be sure that the door
does not bend when installing the cooling fin. The cooling fins are
equipped with packing.
