1. DISPLAY AND OPERATION

B–63175EN/03

Clear

Function

KEY

SETTING

PWE=1

Mode

Function

key

Operation

All memory clear Power ON _

7 and 9

Parameter/offset clear f Power ON _

PARAM

1 + PARAM

Power Mate i–D: 1 path side of dual paths

system

2 + PARAM

Power Mate i–D: 2 path side of dual paths

system

Program clear f Power ON _

DELETE

1 + DELETE

Power Mate i–D: 1 path side of dual paths

system

2 + DELETE

Power Mate i–D: 2 path side of dual paths

system

Alarm clear _ _

CAN or Power OFF/ON

Alarm P/S101 due to power–off

during editing

_ _

CAN and ALARM

PMC RAM clear Power ON _

O and X

Reset

Function

KEY

SETTING

PWE=1

Mode

Function

key

Operation

OT alarm reset Power ON _

P and CAN

Registration from MDI

Function

KEY

SETTING

PWE=1

Mode

Function

key

Operation

Parameter input f – DGNOS /

PARAM

PARAM screen → No. → Number →

INPUT → Data → INPUT → PWE=0 →

CAN

PMC parameter input SETTING

DWE=1

– DGNOS /

PARAM

DGNOS screen → PMC address → Number

→ INPUT → Data → INPUT

Pitch error compensation data

input

f – DGNOS /

PARAM

Pitch error compensation data input screen →

No. → Data Number → INPUT → Data →

INPUT

Setting data input – VAR Setting data screen → Cursor movement →

Data → INPUT

1.10

LIST OF

OPERATIONS

(SETTING AND

DISPLAY UNIT

(DPL/MDI))
