B–63175EN/03

7. TROUBLESHOOTING

423

In this case, the CNC’s status display shows RESET. Refer to item 1.

(2)Only rapid traverse in positioning (G00) does not function Confirm

the following parameter and signals from the PMC.

(a) Setting value of rapid traverse rate

1420 Rapid traverse rate per axis

(b)Rapid traverse override signals

G0014

#6 #5 #4 #3 #2 #1

ROV2

ROV1

ROV1 ROV2 Override

0 0

1 0

0 1

1 1

100%

50%

25%

1421 Rapid traverse override F0 rate

(3)Only feed (other than G00) does not function

(a) Maximum feedrate set by parameter is incorrect.

1422 Maximum feedrate

[mm/min]

1430 Maximum feedrate in each axis

[mm/min]

Feedrate is clamped at this upper feedrate.

(b)Feedrate is specified by feed per revolution (mm/rev)

1) Position coder does not rotate

Check the connection between spindle and position coder

The following failure is considered:

⋅ T iming belt is broken

⋅ Key is removed

⋅ Coupling is loose

⋅ Connector of signal cable is loosened

2) Position coder is faulty

Position coder is connected to the spindle amplifier when serial

interface spindle is used or connected to the Power Mate when

analog interface spindle is used.

i. Power Mate is in a reset

state
