B–63175EN/03

2. HARDWARE

221

The following regulated power supply is required for the input power

supply of the Power Mate controller and peripheral units.

24 VDC ±10% (including instantaneous changes and ripple).

Ripple voltage x 1.2 Vp–p

Table 2.12 (a) Power supply capacity for control unit

Unit

Power supply capacity

Control unit

(No option board is

included.)

1.5 A

(A fuse of 1 A is additionally required if a FANUC

RS–232–C unit is used.)

Option board

HSSB board 0.2A

I/O Link–II slave board 0.3A

I/O Link–II slave board B 0.3A

PROFIBUS–DP master

board

0.3A

PROFIBUS–DP slave

board

0.3A

DeviceNet master board

DeviceNet master board B

DeviceNet slave board

DeviceNet slave board B

DeviceNet slave board C

0.2A

Ethernet board

Fast Ethernet board

0.3A

FL–net board 0.3A

External I/O card D, E 500 + 7.3 x n (mA) where n is the number of

input points that are turned on simultaneously

(*)

I/O Unit–A The required current varies depending on the

number of modules. Refer to the I/O

Unit–MODEL A Connection and Maintenance

Manual (B–61813E).

I/O Link connection unit 0.2 A

Basic connector panel I/O

module

200 + 7.3 x n (mA) where n is the number of

input points that are turned on simultaneously

(*)

Branch–out I/O module

expansion A/B

100 + 7.3 x n (mA) where n is the number of

input points that are turned on simultaneously

(*)

Branch–out I/O module

expansion C/D

0.1A

Operator’s panel I/O

module A1

0.35A

2.12

POWER SUPPLY FOR

CONTROL UNITS
